New nRF52832 Chip Wifi iBeacon Bluetooth Beacon Gateway

FOB Reference Price:Get Latest Price
US $32.5-38 / Pieces | 1 Piece/Pieces (Min. Order)
Contact Supplier Start Order
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
iBeTag
Model Number:
iB006N
Product Name:
New nRF52832 Chip Wifi iBeacon Bluetooth Beacon Gateway
Distance::
130m in open air
Dimensions:
18mm*58mm*85mm
Chipset:
Nordic nrf52832
Color:
Black
Function:
Bluetooth WiFi gateway
Power supply:
USB
Delivery time:
5-7 days
Warranty:
6 months
Customization:
Accepted
Supply Ability
Supply Ability:
10000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Carton Packing
New nRF52832 Chip Wifi iBeacon Bluetooth Beacon Gateway
Port
Shenzhen
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(day) 30 To be negotiated
Video Description
Company Information
BLE WIFI Gateway

2017 New nRF52832 Chip Wifi iBeacon Bluetooth Beacon Gateway

iB006N is a BLE to WiFi gateway and bridge.The gateway reads iBeacon, Eddystone data, or other data from sensors through bluetooth, and it communicates using WiFi through TCP/HTTP sockets to upload the collected readings and/or receive instructions from a central cloud based server

Features

■ Size: 18mm*58mm*85mm(not including antenna)

■ Input: 5V, 500mA, mini-USB
■ Low power consumption, 70mA typical working current
■ Reads multiple BLE devices in the same time
■ Support TCP/HTTP server

Features

BLE
■ 130M range in open space
WiFi
■ 2.4GHz frequency band
■ Connect to Cloud server or local server
■ 130M range in open space

Application

■ iBeacon/Eddystone/tag receiver/Sensors for location tracking
■ BLE sensor reader for sensor network
■ Building automation
■ Health and wellness monitoring
■ Cycling, biking
■ Security
■ Location tracking
■ Access management
■ Advertisement
■ Industrial automation

iBeacon Parameters
WiFi RF Specification
Wireless
IEEE 802.11b/g/n
Network modes
Wi-Fi Direct, soft-AP
Frequency band
2.400 – 2.484 GHz
Channel Bandwidth
20MHz
Modulation
OFDM, DSSS (Direct Sequence Spread Spectrum), DBPSK, DQPSK, CCK , 16QAM, 64QAM
Maximum receive input level
- 10dBm (with PER < 8%@11 Mbps)
- 20dBm (with PER < 10%@54 Mbps)
- 20dBm (with PER < 10%@MCS7)
Minimum receive input level
- 70dBm (typ. with PER < 10%@54 Mbps)
- 70dBm (typ. with PER < 10%@54 Mbps)
- 70dBm (typ. with PER < 10%@MCS7)
Transmit Power
17dBm (typical)@802.11b
13dBm (typical)@802.11g
11dBm (typical)@802.11n
Range
130M in open area
Security
WPA/WPA2
BLE RF Specification
Receiver Sensibility
-96 dBm
Range
130M in open area
Detailed Images
Other Models

iB001N

Bluetooth range: 20-30m
Battery type: CR2032
Working time: 12 months based on broadcasting rate 1second
Size: 27*7.6mm
Chipset: N51822 256KB.

iB003N

Bluetooth range: 100m
Battery type: CR2477
Working time: 58monthsbased on broadcasting rate 1second
Size: 42.3mmx42.3mmx13.4mm
Chipset: N51822 256KB

iB005N

Bluetooth range: 40m
Powered by: USB adapter
Size: 19*15*6mm
Chipset: N51822 256KB

iB004N

Bluetooth range: 75m
Battery type: CR2450
Working time: 30 months based on broadcasting rate 1second
Size: 40*40*13.5mm
Chipset: N51822 256KB

iB001M

Bluetooth range: 70m
Battery type: CR2016
Working time: 10 months based on broadcasting rate 1second
Size: 40.3mm x 23.9mm x 2.6mm
Chipset: N51822 256KB

iB005N-SMA

Bluetooth range: 130m
Powered by: USB adapter
Size: 19*15*6mm
Chipset: N51822 256KB

iB001W

Features: iBeacon data, but Eddystone data is optional
Chipset: N51822 256KB
Bluetooth range: 20m in open air
Battery type: Rechargeable battery
Working time: 1 month based on broadcasting rate 1s every charge
With Vibrator and LED
Color: black, blue, pink, orange, red

Our Service

Case customization
For the bulk purchase consumer, we provide the case customization and even the hardware design just for your customized housing

Logo printing customization
We can print your own logo on the case in any color (Gradient color will relatively cost more).

Firmware customization
We provide the firmware customization.you can change the UUID, major, minor and other parameters.
